ServiceProcedures
AdjustingSteeringDampener
Refertoimageonpreviouspage.
1.Loosen,butDONOTremove,thetwosocketscrewsF
securingthedampenerclampBtothehandcycleframeG.
2.EnsuringthefrontwheelanddampenerclampBareinlinewith
thehandcycleframeG,securelytightenthetwosocketscrews
FsecuringthedampenerclampBtothehandcycleframeG.
3.Testdrivehandcycle,ifhandcyclepullstotheleftorrightrepeat
STEPS1-2untilhandcycledrivesstraight.
6.8InstallingTwenty-SevenorThirtySpeed
CassetteChain
1.SpreadthechainAoutflatandrunitaroundthechainringB
onthecrankDandthesprocketConthehub.
Itmaybenecessarytoturnthehandcrankinaclockwise
motiontopositionthechainonthesmallsprocket.
2.EnsurethatcrankassemblyDisloosened.
3.LiftuponthechainderailleurEandthreadthechainAunder
thederailleurE.
4.ThreadthechainBaroundthewheelsprocketC.
5.RunthechainBaroundthebottomofthewheelsprocketC
andbackuptowardsthehandcranksprocketB.
6.AttachthechainAtogetherusingthemasterlink(w/clip)
provided.
