6.1InstallingRearWheelswithThreadedAxles
WARNING!
–Afteranyadjustments,repairorserviceandbefore
use,makesureallattachinghardwareistightened
securely.Otherwiseinjuryordamagemayoccur.
WARNING!
–DONOTusethehandcycleunlessithastheproper
tirepressure(p.s.i.).DONOToverinflatethetires.
Failuretofollowthesesuggestionsmaycausethetire
toexplodeandcausebodilyharm.tirep.s.i.isprinted
onthetirewall.
1.ApplyasmallamountofgreaseontotheaxlesA.
2.InserttheaxleAintotheaxlemountingholeBonthehandcycle
frameC.Repeatforotherwheel.
3.SecurelyeachwheeltotheframeCwiththe6mmwrenchD.
Thereshouldbenoplayorthreadsvisible.
6.2ReplacingTire/TubeandTuning/Replacement
ofSpokes
Invacarerecommendsthattheseproceduresbeperformed
byaqualifiedtechnician.
6.3ReplacingCamberInserts
1.Loosen,butdonotremovethesocketscrewsAandclampsB
thatsecurethecamberinsertsCtothecamberbarD.
2.RemovetheexistingcamberinsertCfromthecamberbarD.
3.InstallthenewcamberinsertCintothecamberbarD.
4.Adjustthetoein/toeoutofthehandcycle.Referto5.7Adjusting
ToeIn/ToeOut,page50.
