Force™
5.7AdjustingToeIn/ToeOut
1.Loosen,butdonotremovethesocketscrewsAandclampsB
thatsecurecamberinsertsCtothecamberbarD.
2.SlowlyrotatethecamberinsertCuntiltherearwheelsare
approximatelyinastraightline.
3.SecurelytightenthesocketscrewsAandclampsBthatsecure
thecamberinsertsCtothecamberbarD.
4.Measurethedistancebetweenthecenterlinesattherearand
frontoftherearwheelsatapproximately12inches(30cm)
fromtheground/floor.Referto5.6DeterminingToeIn/Toe
Out,page49.
5.RepeatSTEPS1-4untilthetoein/toeoutmeasurementisless
than1/8-inch(0.3175cm)(formaximumrollability).
5.8AdjustingHandCrank
WARNING!
–Afteranyadjustments,repairorserviceandbefore
use,makesureallattachinghardwareistightened
securely.Otherwiseinjuryordamagemayoccur.
DiagonalAdjustment
1.Loosen,butdonotremovetheallennutsthatsecurethecrank
handlestothefork.
2.Slidethecrankhandlesupand/ordownuntilthepropertension
onthechainisachieved.
Theproperchaintensionwillbeapproximately1/2-inch
(1.27cm)ofchainslack.
Ifcrankisindesiredpositionbutchaintensionisnot
correct,linksMUSTbeaddedtoorremovedfromthe
chaintocorrectthetension.
Thisshouldbeperformedbyaqualifiedtechnician.
3.Tightentheclampthatsecuresthecrankhandlestothefork
securely.
501171790-B
