Invacare Force-2 - Replacing;Adjusting the Footrest

ServiceProcedures
6.17Replacing/AdjustingtheFootrest
WARNING!
–Afteranyadjustments,repairorserviceandbefore
use,makesureallattachinghardwareistightened
securely.Otherwiseinjuryordamagemayoccur.
ReplacingFootrest
Ifreplacingfootresttakenoteofcurrentposition.
1.LoosenthehexboltandlocknutAthatsecurethefootrestB
totheforkC.RemovethelocknutA.
2.IfreplacingfootrestBperformthefollowing:
a.RemoveexistingfootrestBfromclampA.
b.Insertnewfootrestintoclamp.
3.SlidefootrestBtodesiredposition.
4.Installthelocknut.Tightensecurely.
5.RepeatSTEPS1-4fortheoppositefootrestifnecessary.
AdjustingFootrestforForceGandForce-2,ForceRXfor
shortleglengths
1.LoosenthefourboltsAthatsecurethefootrestclampBto
thewheelchairframeC.
2.AdjustthefootrestDtothedesiredpositionbyslidingit
throughthefootrestclampB.
3.TightentheboltsAsecurely.
1171790-B67
