Invacare Force-2 - Assembling;Adjusting;Using the Handcycle Rack

Options
9.5Assembling/Adjusting/UsingtheHandcycle
Rack
WARNING!
–Afteranyadjustments,repairorserviceandbefore
use,makesureallattachinghardwareistightened
securely.Otherwiseinjuryordamagemayoccur.
AssemblingtheHandcycleRack
1.PositionthereceiverIwiththebracketKfacingup.
2.PositiontherearwheelbarGwiththewheelbracketsKfacing
up.
3.RemovethetwolargemountingboltsandlocknutsHfromthe
receiverIandsetaside.
4.RemovethetwosmallmountingboltsandlocknutsJfromthe
receiverbracketKandsetaside.
5.SecurethewheeltrayCtothereceiverIwiththetwolarge
mountingboltsandlocknutsH.
6.UsingtwosmallmountingboltsandlocknutsJ,securethe
receiverbracketKtothewheeltrayC.
7.RemovethetwomountingboltsandlocknutsLfromtherear
wheelbarGandsetaside.
8.UsingtwomountingboltsandlocknutsL,securetherearwheel
barGtothewheeltrayC.
9.InstallthereceiverIontothetrailerhitchofthevehicle,
accordingtothevehiclemanufacturer'sinstructions.
AdjustingtheHandcycleRack
WARNING!
–Afteranyadjustments,repairorserviceandbefore
use,makesureallattachinghardwareistightened
securely.Otherwiseinjuryordamagemayoccur.
Toproperlysecurethehandcycle,thewheeltraybracket
shouldbeadjustedtositagainstthefrontwheel.
1171790-B75
