TopEnd
®
Force™
WheelTrayBracket
1.RemovethefourmountingboltsandlocknutsAsecuringthe
wheeltraybracketBtothewheeltrayC.
2.PositionthewheeltraybracketBinthedesiredposition.
3.SecurethewheeltraybracketBtothewheeltrayCwiththe
fourmountingboltsandlocknutsA.
4.Ifnecessary,thewheelstopDmaybeadjustedtooneofthree
positionstositagainstthefrontwheel.Toadjustthewheelstop
D,performthefollowingsteps:
a.RemovethemountingboltandlocknutAsecuringthe
wheelstopDtothewheeltraybracketB.
b.PositionthewheelstopDinthedesiredmountingposition.
c.SecurethewheelstopDtothewheeltraybracketBwith
themountingboltandlocknutA.
RearWheelBarBrackets
Toproperlysecurethehandcycle,therearwheelbar
bracketsshouldbeadjustedtositagainsttherearwheels.
1.LoosenthetwoscrewsEsecuringtherearwheelbarbracket
FtotherearwheelbarG.
2.AdjusttherearwheelbarbracketFin/outuntiltheysitagainst
therearwheel.
3.SecuretherearwheelbarbracketFtotherearwheelbarG
withthetwoscrewsE.
4.Repeatsteps1-3fortheoppositesideifnecessary.
RearWheelBar
Toproperlysecurethehandcycle,therearwheelbarshould
beadjustedsotherearwheelssitintherearwheelbar
brackets.
1.RemovethetwomountingboltsandlocknutsHsecuringthe
rearwheelbarGtothewheeltrayC.
2.PositiontherearwheelbarGtooneofthreemounting
positionsonthewheeltrayC.
3.SecuretherearwheelbarGtothewheeltrayCwiththetwo
mountingboltsandlocknutsH.
