9.6UsingtheAlignmentGauge
1.Inflatethetirestorecommendedtirepressures(listedonthe
sidewallofthetire).
2.PlacethehandcycleandalignmentgaugeAonaflatsurface.
3.PositionthealignmentgaugeAneartherearofthereartiresB.
4.Loosenthealignmentscrewoneachside.
5.PositionthealignmentgaugeAbetweentherearoftherear
tiresB.
6.AdjustthealignmentinsertssothealignmentgaugeAfitssnugly
betweentherearofthereartiresB.
7.Tightenthealignmentscrewstosecurethealignmentbar
position.
8.PositionthealignmentgaugeAatthefrontofthereartires
Bandrepeat.
9.ExaminethegaugeA.Performoneofthefollowing:
a.IfthealignmentgaugeAfitssnuglybetweenthefrontof
thereartires,thewheelsarealigned.Notoein/toeout
adjustmentisrequired.
b.IfthereisextraspacebetweenthealignmentgaugeAand
reartires,thetireshaveatoeoutcondition.Referto5.7
AdjustingToeIn/ToeOut,page50.
c.IfthealignmentgaugeAdoesnotfitbetweenreartires,the
tireshaveatoeincondition.Referto5.7AdjustingToe
In/ToeOut,page50.
FrontofHandcycle
RearofHandcycle
