6.4Removing/InstallingtheFork
ForceKandForceRXONLY(ForceGandForceCCcanonlybe
donebyanauthorizedbicycletechnician)
WARNING!
–Afteranyadjustments,repairorserviceandbefore
use,makesureallattachinghardwareistightened
securely.Otherwiseinjuryordamagemayoccur.
ForForce-2,referto4.1AssemblingtheForce-2Handcycle,
page33
Adjustingtheheightofthecrankmayrequireusingextra
chainsuppliedwiththehandcycle.
Theseproceduresrequiretheuseofa5mmallenwrench
and1/2inch(1.27cm)wrench.
RemovingtheFork
1.Setthefrontoftheframeonastablesurfacethatelevatesthe
frameslightlyofftheground.
2.Removefrontwheel.
3.LoosenthetopcapboltsA.DONOTremove.
4.RemovelowercapboltB.
5.LoosenthelowerforkclampboltsC.DONOTremove.
6.RemovelowercapB.
7.LoosencompensatorsetscrewsD.
8.LoosenthecompensatorboltD.DONOTremove.
9.RemovetheupperforkclampE.
10.RemovethecompensatorboltD.
11.Tiptheforkandslideofftheendoftheforkstem.Retaintop
clamp,capsandbolts.
561171790-B
