6.13DiscBrakes
Cleaning
Undernormaluseandconditions,itisnotnecessarytocleanthe
caliperrotororpads.Ifnecessary,useasolutionofwateranddish
detergenttowashthecaliperandrotor.Thoroughlyrinseallsoap
residuefromtherotor.Drythecomponentscompletelywitha
cleanpapertowel.
CableAdjustment
UsethebarreladjusterBtoremovecableslack.Turnthebarrel
adjusterBuntilthereisnofreeplayinthebrakeleverbutnotsofar
thatthetorquearmonthecaliperCisadvanced.RefertoBrakePad
Replacementimageonpage68.
Thetorquearmshouldreturncompletelywhenthebrake
leverisreleased.
SpringAdjustment
Toadjustspringtension,turnthespringtensionadjustmentscrewE
witha2mmhexwrenchF.Turnthescrewclockwisetoincrease
thespringtension,whichequalsharderleverpull.
BrakePadInspection,ReplacementandBreakIn
AbrakepadMUSTbereplacedwhenitsthickness(backing
plateandfrictionmaterial)islessthan3mm.
Iftherotorisdamagedorexcessivewearisfound,itshould
bereplacedimmediatelybyaqualifiedtechnician.
