Force™
6.9AdjustingTwenty-SevenorThirtySpeed
CassetteChain
1.Loosen,butdonotremovetheclampthatsecurethecrank
handlestothefork.
2.Slidethecrankhandlesupand/ordownuntilthepropertension
onthechainisachieved.
Theproperchaintensionwillbeapproximately1/2-inch
(1.27cm)ofchainslack.
Ifcrankisindesiredpositionbutchaintensionisnot
correct,linksMUSTbeaddedtoorremovedfromthe
chaintocorrectthetension.Thisshouldbeperformed
byaqualifiedtechnician.
3.Tightentheclampthatsecuresthecrankhandlestothefork
securely.
6.10InstallingHandCrankHandles
WARNING!
–Replacement/installationofVorScrankhandles
shouldbedonebyaqualifiedtechnician
6.11InstallingV/SCrankarmHandles
WARNING!
–Afteranyadjustments,repairorserviceandbefore
use,makesureallattachinghardwareistightened
securely.Otherwiseinjuryordamagemayoccur.
–Failuretoinstallhandleassemblyproperlycouldresult
ininjury.
–Itisrecommendedtoinspectthisassemblypriorto
andaftereachuse.
ScrewhandleAintocrankarmhousingB(righthandlehas
right-handedthread;lefthandlehasleft-handedthread).
Handleshouldspinfreelywithminimalplay.Ifhandledoes
notspinfreely,contactTopEndCustomerServiceatthe
phonenumberonthebackcoverofthismanual.
