Invacare Perfecto2 IRC5PO2AW User Manual

SECTION 5—TYPICAL PRODUCT PARAMETERS
Perfecto
2
™Series 14 Part No 1160877
Maximum Outlet
Pressure: 34.5 kPa ± 3.45 kPa (5 psi ± 0.5 psi)
Flow Range: 0.5 to 5 L/min (maximum)
For flowrates less than 1 L/min, we recommend the use of the
Invacare Pediatric Flowmeter Accessory (IRCPF16AW)
Low Flow Alarm: 0 L/min to 0.5 L/min
Rapid Audible Alarm Beeping (No Accessories Connected)
Average Power
Consumption:
Perfecto
2
AW - 300 W @ 5 L/min, 280 W @ 3 L/min
Perfecto
2
VAW - 320 W@ 5 L/min
Pressure Relief
Mechanism
Operational at: 241 kPa ± 24.1 kPa (35 psi ± 3.5 psi)
Change in maximum
recommended flow
when back pressure
of 7kPa is applied: 0.7 L/min
Filters: Cabinet, Outlet HEPA and Compressor Inlet
Safety System: Current overload or line surge shutdown
High temperature compressor shutdown
High Pressure Alarm w/compressor shutdown
Low Pressure Alarm w/compressor shutdown
Battery Free Power Loss Alarm
SensO
2
Oxygen System (SensO
2
Model) Low Flow Alarm
Width: 38.1 cm ± 1 cm (15 in ± 3/8 in)
Height: 58.4 cm ± 1 cm (23 in ± 3/8 in)
Depth: 30.5 cm ± 1 cm (12 in ± 3/8 in)
Weight: Perfecto
2
AW Models - 20.5 kg ± 1 kg (45 lbs ± 2 lbs)
Perfecto
2
VAW Models - 18.1 kg ± 1 kg (40 lbs ± 2 lbs)
Shipping Weight: Perfecto
2
AW Models - 22.7 kg ± 1 kg (50 lbs ± 2 lbs)
Perfecto
2
VAW Models - 20.4 kg ± 1 kg (45 lbs ± 2 lbs)
Operating Ambient
Temperature: 10°C - 35°C (50°F - 95°F) at 20-60% relative humidity
Exhaust Cooling Air
Temperature: Less than Ambient +19°C (+ 35°F)
Oxygen Output
Temperature: Less than Ambient +3°C(+ 6°F)
>

Invacare Perfecto2 IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Warranty	3 years limited
Operating Environment	10°C to 35°C; up to 95% relative humidity
Power Requirements	120 VAC, 60 Hz
Sound Level	≤45 dB(A)
Dimensions	23 in (H) x 13 in (W) x 12 in (D) (58.4 cm (H) x 33 cm (W) x 30.5 cm (D))
