Pagina 13
18 633/25 554/21.8554/21.8
24 633/25 554/21.8554/21.8
36 759/29.8 554/21.8554/21.8
36 633/25 600/23.6600/23.6
48 759/29.8 710/28710/28
60 843/33 710/28710/28
760x590x285 (29.9x23.2x11.2) 530 (20.85) 290 (11.4)
810x558x310 (31.9x22x12.2) 549 (21.6) 325 (12.8)
845x700x320 (33.27x27.5x12.6) 560 (22) 335 (13.2)
900x860x315 (35.4x33.85x12.4) 590 (23.2) 333 (13.1)
945x810x395 (37.2x31.9x15.55) 640 (25.2) 405 (15.95)
990x965x345 (38.98x38x13.58) 624 (24.58) 366 (14.4)
946x810x420 (37.24x31.9x16.53) 673 (26.5)
403 (15.87)
946x810x410 (37.24x31.9x16.14) 673 (26.5)
403 (15.87)
952x1333x410 (37.5x52.5x16.14) 634 (24.96)
404 (15.9)
952x1333x415 (37.5x52.5x16.34) 634 (24.96)
404 (15.9)
845x702x363 (33.27x27.6x14.3)
540 (21.26)
350 (13.8)
938x1369x392 (36.93x53.9x15.43) 634 (24.96) 404 (15.9)
900x1170x350 (35.4x46x13.8) 590 (23.2) 378 (14.88)
800x554x333 (31.5x21.8x13.1) 514 (20.24) 340 (13.39)
>120cm / 47”
>30cm / 11.8”
>30cm / 11.8”
>30cm / 11.8”
>30cm / 11.8”
Fig. 5.4
Fig. 5.7
Fig. 5.5
Fig. 5.8
Fig. 5.9
Fig. 5.6
Unitate exterioara tip SPLIT
Consultati (Refer to Fig 5.4, 5.5, 5.6, 5.10 si tabelul 5.1)
Tabel 5.1: Dimensiunile unitatilor exterioare de tip split
(mm/inch)
Tabel 5.1: Dimensiunile unitatilor exterioare
cu evacuare verticala (mm/inch)
Unitate exterioara cu evacuare verticala
Consultati (Refer to Fig 5.7, 5.8, 5.9 si tabelul 5.2)
(perete sau obstacol)
evacuare aer
L
A
L
H
A
B
L
Dimensiunile unitatii exterioare
LxHxA
Dimensiuni montaj
Distanta B
H
Distanta A
L A
Model
Dimensiuni
