Version 1.00 | Optidrive ODE-3 User Guide | 5www.invertekdrives.com
Quick Start Up
1
1.2. Quick Start Process
Step Action See section Page
1 Identify the Enclosure Type, Model Type and ratings of
your drive from the model code on the label. In particular
- Check the voltage rating suits the incoming supply
- Check the output current capacity meets or exceeds the
full load current for the intended motor
2.1. Identifying the Drive by Model Number 7
2 Unpack and check the drive. Notify the supplier and
shipper immediately of any damage.
3 Ensure correct ambient and environmental conditions for
the drive are met by the proposed mounting location.
9.1. Environmental 34
4 Install the drive in a suitable cabinet (IP20 Units) ensuring
suitable cooling air is available.
3.1. General
3.3. Mechanical Dimensions and Mounting – IP20
Open Units
3.4. Guidelines for Enclosure Mounting
9
9
10
5 Select the correct power and motor cables according
to local wiring regulations or code, noting the maximum
permissible sizes
9.2. Rating Tables 34
6 If the supply type is IT or corner grounded, disconnect the
EMC filter before connecting the supply.
9.5. EMC Filter Disconnect 36
7 Check the supply cable and motor cable for faults or short
circuits.
8 Route the cables.
9 Check that the intended motor is suitable for use, noting
any precautions recommended by the supplier or
manufacturer.
4.9. EMC Compliant Installation 15
10 Check the motor terminal box for correct Star or Delta
configuration where applicable.
4.5. Motor Terminal Box Connections 13
11 Ensure wiring protection is providing, by installing a
suitable circuit breaker or fuses in the incoming supply line.
4.3.2. Fuse / Circuit Breaker Selection
9.2. Rating Tables
12
34
12 Connect the power cables, especially ensuring the
protective earth connection is made.
4.1. Connection Diagram
4.2. Protective Earth (PE) Connection
4.3. Incoming Power Connection
4.4. Motor Connection
11
11
12
12
13 Connect the control cables as required for the application. 4.6. Control Terminal Wiring
4.9. EMC Compliant Installation
7. Analog and Digital Input Macro Configurations
7.2. Example Connection Diagrams
13
15
27
27
14 Thoroughly check the installation and wiring.
15 Commission the drive parameters. 5.1. Managing the Keypad
6. Parameters
16
18
