7. Analog and Digital Input Configurations
7.1. Terminal mode (P1-12 =0)
P2-01 Digital input 1 (T2) Digital input 2 (T3)
Analog Input 1 (T4
)
(or Digital Input 3)
Analog input
2
(T5
)
(or Digital Input 4)
0
Open: Stop (disable)
Closed: Run (enable)
Open : Bipolar analog speed ref
Closed : Preset speed ref
Bipolar Analog Input
Open :
Preset Speed 1
Closed : Preset Speed 2
1
Open: Stop (disable)
Closed: Run (enable)
Open: Preset Speed 1
Closed: Preset speed 2
Open : Preset Speed 1 / 2 / 3
Closed : Preset Speed 4
Open : Preset Speed 1 / 2
Closed : Preset Speed 3
2
Open: Stop (disable)
Closed: Run (enable)
Digital Input 2
Digital Input 3
Digital Input 4
Speed Setpoint
Open
Open
Open
Preset Speed 1
Closed
Open
Open
Preset Speed 2
Open
Open
Closed
Preset Speed 3
Closed
Open
Closed
Preset Speed 4
Open
Closed
Open
Preset
Speed 5
Closed
Closed
Open
Preset Speed 6
Open
Closed
Closed
Preset Speed 7
Closed
Closed
Closed
Preset Speed 8
3
Open: Stop (disable)
Closed: Run (enable)
Open :
Forward
Closed : Reverse
Bipolar Analog Input
Open: Bipolar analog ref
Closed: Preset Speed 1
4
Open: Stop (disable)
Closed: Run (enable)
Open :
Forward
Closed : Reverse
Bipolar Analog Input
Analog input 2
(E.g. Torque reference)
5
Open: Stop (disable)
Closed: Run (enable)
Open : Forward
Closed : Reverse
Digital Input 3
Digital
Input 4
Speed Setpoint
Open
Open
Preset Speed 1
Open
Closed
Preset Speed 2
Closed
Open
Preset Speed 3
Closed
Closed
Preset Speed 4
6
Open: Stop (disable)
Closed: Run (enable)
Open : Forward
Closed : Reverse
Bipolar Analog Input
External
trip input :
Open: Trip,
Closed: No Trip
7
Open: Stop (disable)
Closed: Fwd Run (enable)
Open: Stop (disable)
Closed: Rev Run (enable)
Bipolar Analog Input
Open: Bipolar analog speed ref
Closed: Preset Speed 1
8
Open: Stop (disable)
Closed: Fwd Run (enable)
Open: Stop (disable)
Closed: Rev Run (enable)
Bipolar Analog Input
Open: Bipolar analog speed ref
Closed: Preset Speed 1
9
Open: Stop (disable)
Closed: Forward Run (enable)
Open: Stop (disable)
Closed: Reverse Run (enable)
Digital Input
3
Digital Input 4
Preset Speed
Open
Open
Preset Speed 1
Open
Closed
Preset Speed 2
Closed
Open
Preset Speed 3
Closed
Closed
Preset Speed 4
10
Open: Stop (disable)
Closed: Forward Run (enable)
Open: Stop (disable)
Closed: Reverse Run (enable)
Bipolar Analog Input
External trip input :
Open: Trip,
Closed: No Trip
11
Open: Stop (disable)
Closed: Run (enable)
Open : Bipolar analog speed ref
Closed : Preset speed 1
Bipolar Analog Input
External trip input :
Open: Trip,
Closed: No Trip
12
Open: Stop (disable)
Closed: Run (enable)
Open : Preset Speed 1
Closed : Bipolar analog speed ref
Bipolar Analog Input
External trip input :
Open: Trip,
Closed: No Trip
13
Normally Open (NO)
Momentarily Close to Run
Normally Closed (NC)
Momentarily Open to Stop
Bipolar Analog Input
Open: Bipolar analog speed ref
Closed: Preset Speed 1
14
Normally Open (NO)
Momentarily Close to Run Fwd
Normally Closed (NC)
Momentarily Open to Stop
Bipolar Analog Input
Normally Open (NO)
Momentarily Close to Run Rev
15
Open: Stop (disable)
Closed: Run (enable)
Open : Forward
Closed : Reverse
Bipolar Analog Input
Open: Decel Ramp 1 (P1
-
04)
Closed: Decel Ramp 2 (P2-25)
16
Open: Stop (disable)
Closed: Run (enable)
Open : Forward
Closed : Reverse
Open:
Preset Speed 1
Closed: Preset Speed 2
Open: Decel Ramp 1 (P1
-
04)
Closed: Decel Ramp 2 (P2-25)
17
Normally Open (NO)
Momentarily Close to Run Fwd
Normally Closed (NC)
Momentarily Open to Stop
Open : Preset Speed 1
Closed : Keypad Mode
Normally Open (NO)
Momentarily Close to Run Rev
18
Open: Stop (disable)
Closed: Run (enable)
Digital Input 2
Digital Input 4
Open : Terminal Mode
Closed : Keypad Mode
Preset Speed Ref
Open
Open
Preset Speed 1
Closed
Open
Preset Speed 2
Open
Closed
Preset Speed 3
Closed
Closed
Preset Speed 4
19
Open: Stop (disable)
Closed: Run (enable)
Open : Bipolar analog speed ref
Closed : Analog input 2 speed ref
Bipolar Analog Input Analog input 2
20
Open: Stop (disable)
Closed: Run (enable)
No Function Bipolar Analog Input
Open :
Bipolar analog speed ref
Closed : Preset Speed 1
21
Open: Stop (disable)
Closed: Run (enable)
No Function Bipolar Analog Input
Open : Forward
Closed : Reverse
22
Open: Stop (disable)
Closed: Run (enable)
No Function Bipolar Analog Input
External trip
input :
Open: Trip,
Closed: No Trip
NOTE
Negative Preset Speeds will be inverted if Run Reverse selected.
The external trip input can be used to connect a motor thermistor by connecting the thermistor between terminals 1 and 4
