INVT GD10-0R7G-4-B User Manual

Goodrive10 Series Mini VFD Product overview
-8-
Function
Specification
combination and the set channel
Automatic voltage
regulation function
Keep the output voltage constant when grid
voltage changes
Fault protection
function
Provides more than 10 kinds of fault protection
functions: overcurrent, overvoltage,
undervoltage, over-temperature, overload, and
so on
Others
Installation mode
Wall mounting
Temperature of
running environment
-10–50°C. If temperature is above 40°C, derate
1% for every additional 1°C .
Cooling mode
Natural air cooling for 1PH/3PH 220V
0.2-0.75kW
Forced air cooling for 1PH/3PH 220V 1.5-2.2kW
and 3PH 380V 0.75-2.2kW
Pollution level
Level 2
Braking unit
Built-in, select optional braking units according
to the lot number.
Braking resistor
Optional and external
DC reactor
Not optional
EMC filter
C2 filter is optional.
C3 input filter is optional for some models.
2.3 Product nameplate
Model: GD10-2R2G-4-B
Power(Output): 2.2kW
Input: AC 3PH 380V(-15%)-440V(+10%) 7.1A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 5.5A 0Hz-400Hz
Made in ChinaS/N:
Shenzhen INVT Electric Co., Ltd.
IP00
Figure 2-1 Product nameplate
Note: This is a nameplate example of a standard VFD product. The CE/TUV/IP marking on
the top right will be marked according to actual certification conditions.

INVT GD10-0R7G-4-B Specifications

General

Brand	INVT
Model	GD10-0R7G-4-B
Category	Inverter
Language	English
