INVT GD10-0R7G-4-B User Manual

Goodrive10 Series Mini VFD Function parameters
-71-
Function
code
Name
Description
Default
Modify
overload/underload fault.
LED hundreds :
0: Always detect
1: Detect during constant-speed running
Setting range of P11.09: P11.11–200%
Setting range of P11.10: 0.1–60.0s
P11.11
Underload
pre-alarm
detection
level
Underload pre-alarm signal will be outputted if
the output current of the VFD or motor is lower
than underload pre-alarm detection level
(P11.11), and the duration exceeds underload
pre-alarm detection time (P11.12).
Setting range of P11.11: 0–P11.09
Setting range of P11.12: 0.1–60.0s
50%
○
P11.12
Underload
pre-alarm
detection
time
1.0s
○
P11.13
Fault
output
terminal
action
upon fault
occurring
The function code is used to set the action of
fault output terminals at undervoltage and fault
reset.
0x00–0x11
LED ones:
0: Act at undervoltage
1: Do not act at undervoltage
LED tens:
0: Act at fault reset
1: Do not act at fault reset
0x00
○
P14 group Serial communication
Function
code
Name
Description
Default
Modify
P14.00
Local
communication
address
Setting range:1–247
When the master is writing the frame, the
communication address of the slave is set
to 0; the broadcast address is the
communication address. All slaves on the
Modbus fieldbus can receive the frame, but
the salve doesn’t answer.
The communication address of the drive is
1
○
