Goodrive10 Series Mini VFD Function parameters
-47-
Function
code
Name
Description
Default
Modify
P05.41
AI2 input
filter time
Note: AI2 supports 0–10V or 0–20mA input,
when AI2 selects 0–20mA input, the
corresponding voltage of 20mA is 10V.
Setting range of P05.32: 0.00V–P05.34
Setting range of P05.33: -100.0%–100.0%
Setting range of P05.34: P05.32–10.00V
Setting range of P05.35: -100.0%–100.0%
Setting range of P05.36: 0.000s–10.000s
Setting range of P05.37: 0.00V–P05.39
Setting range of P05.38: -100.0%–100.0%
Setting range of P05.39: P05.37–10.00V
Setting range of P05.40: -100.0%–100.0%
Setting range of P05.41: 0.000s–10.000s
0.100s
○
P06 group Output terminals
Function
code
Name
Description
Default
Modify
P06.01
Y output
selection
0: Invalid
1: In running
2: In forward running
3: In reverse running
4: In jogging
5: VFD fault
6: Frequency level detection FDT1
8: Frequency reached
9: Running in zero speed
10: Reach frequency upper limit
11: Reach frequency lower limit
12: Ready to run
14: Overload pre-alarm
15: Underload pre-alarm
18: Reach set counting value
19: Reach designated counting value
20: External fault is valid
22: Reach running time
23: Virtual terminals output of Modbus
communication
0
○
P06.03
Relay RO
output
selection
1
○
