Goodrive10 Series Mini VFD Technical data
-105-
but it specifies their use, installation, and commissioning. Specialized personnel or
organizations must have the necessary skills (including the EMC-related knowledge) for
installing and/or performing commissioning on the electrical drive systems.
C3: Rated voltage lower than 1000 V, applied to environments of Category II. They cannot
be applied to environments of Category I.
C4: Rated voltage higher than 1000 V, or rated current higher or equal to 400 A, applied to
complex systems in environments of Category II.
A.3.1 VFDs of category C2
The induction disturbance limit meets the following stipulations:
1. Select an optional EMC filter according to Appendix D Optional peripheral accessories
and install it following the description in the EMC filter manual.
2. Select the motor and control cables according to the description in the manual.
3. Install the VFD according to the description in the manual.
Currently in environments in China, the VFD may generate radio
interference, you need to take measures to reduce the interference.
A.3.2 VFDs of category C3
The anti-interference performance of the VFD meets the requirements of environments
Category II in the IEC/EN 61800-3 standard.
The induction disturbance limit meets the following stipulations:
1. Select an optional EMC filter according to Appendix D Optional peripheral accessories
and install it following the description in the EMC filter manual.
2. Select the motor and control cables according to the description in the manual.
3. Install the VFD according to the description in the manual.
VFDs of category C3 cannot be applied to civilian low-voltage common
grids. When applied to such grids, the VFDs may generate radio
frequency electromagnetic interference.
