INVT GD10-0R7G-4-B User Manual

Goodrive10 Series Mini VFD Product overview
-9-
2.4 Mode code
The model code contains product information. You can find the model code on the VFD
nameplate or simplified nameplate.
GD10 – 2R2G – 4 - B
① ② ③ ④
Figure 2-2 Product model
Field
Sign
Description
Contents
Abbreviation of
product series
①
Abbreviation of product series
GD10: Goodrive10 series mini
VFD
Rated power
②
Power range + Load type
2R2: 2.2kW
G: Constant torque load
Voltage level
③
Voltage level
4: 380(-15%)–440(+10%)
2: 220(-15%)–240(+10%)
S2: 220(-15%)–240(+10%)
Lot No.
④
Lot No.
B: Standard braking unit
2.5 Rated specifications
Model
Output power
(kW)
Input current
(A)
Output current
(A)
1PH 220V
GD10-0R2G-S2-B
0.2
4.9
1.6
GD10-0R4G-S2-B
0.4
6.5
2.5
GD10-0R7G-S2-B
0.75
9.3
4.2
GD10-1R5G-S2-B
1.5
15.7
7.5
GD10-2R2G-S2-B
2.2
24
10
3PH 220V
GD10-0R2G-2-B
0.2
1.9
1.6
GD10-0R4G-2-B
0.4
2.7
2.5
GD10-0R7G-2-B
0.75
4.9
4.2
GD10-1R5G-2-B
1.5
9.0
7.5
GD10-2R2G-2-B
2.2
15
10
3PH 380V
GD10-0R7G-4-B
0.75
3.2
2.5
GD10-1R5G-4-B
1.5
4.3
4.2
GD10-2R2G-4-B
2.2
7.1
5.5
