Goodrive300-01 inverter for air compressor Function parameters
-12-
Chapter 3 Function parameters
For the convenience of function codes setting, the function group number corresponds to the first
level menu, the function code corresponds to the second level menu and the function code
corresponds to the third level menu.
1. Below is the instruction of the function lists:
The first line “Function code”: codes of function parameter group and parameters;
The second line “Name”: full name of the function parameters;
The third line “Detailed instruction of parameters”: detailed instruction of the function parameters; the
function parameter will restore to the default value during default parameters restoring, but the
detected parameter or recorded value will not be refreshed.
The fourth line “Default value”: the original factory values of the function parameters;
The fifth line “Modify”: the modifying attribute of the function codes (the parameters can be modified
or not), below is the instruction:
“○”: means the setting value of the parameter can be modified at stopping and running state;
“◎”: means the setting value of the parameter cannot be modified at running state;
“●”: means the value of the parameter is the real detection value which cannot be modified;
(The modification attribute of all parameters are inspected and restricted automatically by the inverter
to avoid mal-modification of users.)
3.1 Basic function parameters
Function
code
Name
Detailed instruction of parameters
Default
value
Modif
y
P00 Group Basic function group
P00.00
Speed control
mode
0: Sensorless vector control mode 0 (apply to AM
and SM)
No need to install encoders. It is suitable in cases
with low frequency, big torque and high speed
control accuracy for accurate speed and torque
control. Relative to mode 1, this mode is more
suitable for medium and small power.
1: Sensorless vector control mode 1 (apply to AM)
No need to install encoders. It is suitable in cases
with high speed control accuracy for accurate speed
and torque control at all power ratings.
2: SVPWM control
No need to install encoders. It can improve the
control accuracy with the advantages of stable
operation, valid low-frequency torque boost and
current vibration suppression and the functions of
slip compensation and voltage adjustment.
3. PMSM
0
◎
