INVT GD300-01-7R5G-4

Goodrive300-01 inverter for air compressor Function parameters
-76-
Function
code
Name
Detailed instruction of parameters
Default
value
Modif
y
P17.28
ASR controller
output
The percentage of the rated torque of the relative
motor, display ASR controller output
Range: -300.0%~300.0% (motor rated current)
0.0%
●
P17.29
Magnetic pole
angle of SM
Display magnetic pole angle of synchronous motor
Range: 0.0~360.0
0.0
●
P17.30
Phase
compensation of
SM
Display phase compensation of synchronous motor
Range: -180.0~180.0
0.0
●
P17.31
High-frequency
superposition
current of SM
Display high-frequency superposition current of
synchronous motor
Range: 0.0%~200.0% (motor rated current)
0.0
●
P17.32
Magnetic flux
linkage
Display the magnetic flux linkage of the motor
Range: 0.0~200.0%
0.0%
●
P17.33
Exciting current
reference
Display the exciting current reference in the vector
control mode
Range: -3000.0~3000.0A
0.0A
●
P17.34
Torque current
reference
Display the torque current reference in the vector
control mode
Range: -3000.0~3000.0A
0.0A
●
P17.35
AC current
Display the value of inlet current at AC side
Range: 0.0~5000.0A
0.0A
●
P17.36
Output torque
Display the output torque. During FWD rotation, the
positive value is in electromotion state while the
negative value is in power generating state. During
REV rotation, the states are on the contrary.
Range : -3000.0Nm~3000.0Nm
0.0Nm
●
P17.37
Counting value of
motor overload
0~100 (100 reports OL1 fault)
0
●
P17.38
PID output
-100.00~100.00%
0.00%
●
P17.39
Wrong download
of parameters
0.00~99.99
0.00
●
3.2 Specific function parameters
Function
code
Name
Detailed instruction of parameters
Default
value
Modif
y
P18 Group Special function group for air compressor
P18.00
Control mode
0: Invalid
1: Control mode for air compressor
0
◎
