INVT GD300-01-7R5G-4

Goodrive300-01 inverter for air compressor Function parameters
-77-
Function
code
Name
Detailed instruction of parameters
Default
value
Modif
y
P18.01
Sleep function
0: Invalid
1: Sleep mode 1
2: Sleep mode 2
1
◎
P18.02
Load and unload
mode
0X00~0X11
LED ones:
0: Automatic
1: Manual
In manual mode, the air compressor is loaded and
unloaded by manual after start-up; in automatic
mode, the air compressor loads and unloads
automatically according to pressure after start-up.
LED tens:
0: Auto load mode 1
1: Auto load mode 2
00
◎
P18.03
Channel of
temperature
sensor
0: PT100 connected to AI2 via temperature
transmitter
1: PT100 connected directly
1
◎
P18.04
Upper limit of
pressure sensor
0.00~20.00
1.60Mpa
◎
P18.05
Unloading
pressure
0.00~ P18.04
Under automatic mode, after the air compressor
starts, unload automatically when the air supply
pressure is higher than the set value.
0.80Mpa
○
P18.06
Loading pressure
0.00~ P18.04
Under automatic mode, after the air compressor
starts, load automatically when the air supply
pressure is lower than the set value; wake up
automatically at hibernation.
0.60Mpa
○
P18.07
Set pressure
0.00~ P18.04
Set the air supply pressure for air compressor at
stable running.
0.70Mpa
○
P18.08
Fan start
temperature
-20~150°C
When the exhaust temperature is higher than the set
value, start the fan.
75°C
○
P18.09
Fan stop
temperature
-20~150°C
When the exhaust temperature is lower than the set
value, stop the fan.
65°C
○
P18.10
Set temperature
-20~150°C
Set the exhaust temperature for air compressor at
75°C
○
