Goodrive300-LIFT series inverter Product overview
-10-
Function
Specifications
Speed fluctuation
± 0.3%(sensorless vector control)
Torque response
<20ms(sensorless vector control)
Torque control
accuracy
10% (sensorless vector control)
Starting torque
For asynchronous motor sensorless vector control:
0.3Hz/150%
For sensor-included vector control: 0 Hz/200%
Overload capability
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Running
control
feature
Frequency setting
method
Digital setting, analog setting, multi-step speed running
setting, and MODBUS communication setting
implement switching between channels.
Voltage
auto-adjustment
Keep constant voltage automatically when the grid
voltage transients.
Fault protection
Provide more than 30 fault protection functions against
faults such as overcurrent, overvoltage, undervoltage,
overheating, phase loss and overload.
Peripheral
interface
Analog input
1 input (AI1): 0–10V/0–20mA
Resolution: ≤20mV
Analog output
1 output (AO1): 0–10V/0–20mA
Resolution: ≤20mV
Digital input
8 common inputs; Max. frequency: 1kHz; internal
impedance: 3.3kΩ;
1 high speed input; Max. frequency: 50kHz
Resolution: ≤2ms
Digital output
1 terminal Y for open collector output
Relay output
3 NO programmable relay outputs;
RO1A NO, RO1C common terminal
RO2A NO, RO2C common terminal
RO3A NO, RO3C common terminal
Contactor capability: 3A/AC250V，1A/DC30V
Power output
Provides 24V/200mA and 10V/50mA power output.
PG expansion card
(optional)
Incremental 5–24V; sine and cosine; absolute value;
UVW
