Goodrive300-LIFT series inverter Peripheral optional parts
-165-
D.7.1 Filter type designation key
FLT-P 04 045 L-B
A B C D E F
Key
Description
A
FLT: inverter filter series
B
Filter type
P: power supply filter
L: output filter
C
Voltage degree
04: AC 3PH 380V(-15%)–440V(+10%)
D
3 bit rated current code. "015" means 15A.
E
Filter performance
L: Common
H: High performance
F
Filter utilization environment
A: First environment (IEC61800-3:2004)category C1 (EN 61800-3:2004)
B: First environment (IEC61800-3:2004)category C2 (EN 61800-3:2004)
C: Second environment (IEC61800-3:2004)category C3 (EN 61800-3:2004)
D.7.2 AC 3PH 380V(-15%)–440V(+10%)
Model
Input filter
Output filter
GD300L-004G-4
FLT-P04016L-B
FLT-L04016L-B
GD300L-5R5G-4
GD300L-7R5G-4
FLT-P04032L-B
FLT-L04032L-B
GD300L-011G-4
GD300L-015G-4
FLT-P04045L-B
FLT-L04045L-B
GD300L-018G-4
GD300L-022G-4
FLT-P04065L-B
FLT-L04065L-B
GD300L-030G-4
Note:
1. The input EMI meet the requirement of C2 after installing input filters.
2. Above options are external, the customer should indicate when purchasing.
