Goodrive300-LIFT series inverter Product overview
-11-
Specifications
IO expansion cards
(optional)
3 common digital inputs
1 analog input AI2
1 NO/NC relay output
1 HDO output
1 Y output
1 RS485 interface (supporting RTU)
1 CAN communication interface
STO expansion card
(optional)
Provides STO security terminal functions.
Bluetooth/Ethernet
expansion card
(optional)
Commissions devices through Bluetooth or Ethernet
communication.
Wall mounting
Running environment
temperature
-10–50˚C. The inverter must be derated if temperature
is above 40˚C.
100,000 hours
IP20
Forced air cooling
Built in inverters ≤15kW; optional for others
DC reactors are standard configuration for inverters
≥18.5kW.
Optional filters C2 can be configured, meeting
IEC618000-3 C2 requirements.
3.4 Name plate
Figure 3-4 Name plate
Note: The certification mark such as "CE" can be placed only after the product is certified.
3.5 Type designation key
The type designation contains inverter information. You can find the type designation on the type
designation label attached to the inverter or the simple name plate.
Model: GD300L-5R5G-4
Power(Output): 5.5kW
Input: AC 3PH 380V(-15%)-440V(+10%) 19.5A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 14A 0Hz-400Hz
Shenzhen INVT Electric Co., Ltd.
S/N: Made in China
