INVT GD300L-004G-4 User Manual

Goodrive300-LIFT series inverter Function parameters
-46-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P05.03
S3 function
selection
6: Fault reset (RET)
7: External fault (EF)
8: Multi-speed running terminal 1 (MS1)
9: Multi-speed running terminal 2 (MS2)
10: Multi-speed running terminal 3 (MS3)
11: Up forced deceleration 1 (UFS1)
12: Up forced deceleration 2 (UFS2)
13: Up forced deceleration 3 (UFS3)
14: Down forced deceleration 1 (DFS1)
15: Down forced deceleration 2 (DFS2)
16: Down forced deceleration 3 (DFS3)
17: Contactor feedback signal (TB)
18: Brake feedback signal (FB)
19: Enable inverter (ENA)
20: Forced decelerate to stop
21: Emergency mode
22: Motor overheat
23: Main power supply input disconnected (for
India)
24: UPS input disconnected by main control (for
India)
25: Base lockout
26–40: Reserved
8
◎
P05.04
S4 function
selection
9
◎
P05.05
S5 function
selection
3
◎
P05.06
S6 function
selection
4
◎
P05.07
S7 function
selection
0
◎
P05.08
S8 function
selection
0
◎
P05.09
S9 function
selection
◎
P05.10
S10 function
selection
◎
P05.11
S11 function
selection
◎
P05.12
HDI function
selection
0
◎
P05.13
Polarity selection
of input terminals
The function code is used to set the polarity of
input terminals.
Set the bit to 0, the input terminal is positive.
Set the bit to 1, the input terminal is negative.
BIT11
BIT10
HDI
S11
BIT9
BIT8
BIT7
BIT6
BIT5
S10
S9
S8
S7
S6
BIT4
BIT3
BIT2
BIT1
BIT0
S5
S4
S3
S2
S1
Setting range: 0x000–0x7FF
0x000
○
P05.14
Digital filter time
Set the sample filter time of S1–S11 and HDI
terminals. If the interference is strong, increase
the parameter to avoid the disoperation.
0.000–1.000s
0.010s
○

INVT GD300L-004G-4 Specifications

General

Model	GD300L-004G-4
Output Power	4 kW
Overload Capacity	150% for 60 seconds
Frequency Range	0-400 Hz
Control Mode	V/F control, Vector control
Cooling Method	Forced Air Cooling
Storage Temperature	-20°C to +60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Communication Interface	RS485
Type	Inverter
Input Voltage	3-Phase 380V (-15%) - 440V (+10%)
Output Voltage	3-Phase 0-Rated Input Voltage
Rated Output Current	9.0 A
Protection Features	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Operating Temperature	-10°C to +50°C
Altitude	Below 1000 m
Efficiency	≥98%
