Goodrive300-LIFT series inverter Function parameters
-72-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P17.17
ASR controller
output
Display ASR controller output in vector control
mode, relative to the percentage of the motor
rated torque.
Setting range: -300.0%–300.0% (motor rated
current)
0.0%
●
P17.18
Actual frequency
detected by the
encoder
Actual frequency detected by the encoder. If the
motor rotates forward, the value is positive; if the
motor rotates reverse, the value is negative.
Setting range: -3276.8–3276.7Hz
0.00Hz
●
P17.19
Encoder pulse
count
Position counting of the encoder, 4 times of the
frequency
Setting range: 0–65535
0
●
P17.20
Encoder Z-pulse
count
Setting range: 0–65535
0
●
P17.21
Magnetic pole
position angle
Setting range: 0.00–359.99
0．00
●
P17.22
Initial magnetic
pole position
angle
Relative angle between the encoder position
and motor magnetic pole position.
Setting range: 0.00–359.99
0.00
●
P17.23
Encoder
C-phase AD
value
Sine-cosine encoder C-signal amplitude
0–4095
0
●
P17.24
Encoder
D-phase AD
value
Sine-cosine encoder D-signal amplitude
0–4095
0
●
P17.25
Motor pole pairs
Display the number of motor pole pairs.
0–65535
0
●
P17.26
Function code of
function
parameter
upload/downloa
d fault
Function codes of faults that occur during
function parameter upload or download
0.00–29.00
0
●
P17.27
Reserved
0–65535
●
P17.28
Reserved
0–65535
●
P18 Group Reserved
