INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Basic Operation Instructions
-92-
0
1
2
3
4
5
.
.
.
.
29
30
P06.01
P06.03
P06.04
P06.02
T delay
T delay
T delay
T delay
0
1
P06.05 output polarity
selection
（Default value: 0）
（Default value: 0）
（Default value: 1）
（Default value: 5）
P06.00
HDO
input type
0
1
0
1
0
1
delay
0
1
-1
-1
-1
-1
P17.13
Digital output
terminal state
P07.40
Output terminal
state of present
fault
Fault?
Fault
Run
Y BIT0 HDO BIT1
ROI BIT2 RO2 BIT3
P06.05, P17.13, P07.40 display
P06.00
0: Open collector high-
speed pulse output
1: Open collector output
P06.07
P06.09
P06.11
P06.13
Y
RO2
ROI
HDO
Digital switch-off delay
Digital output selection
T delay
T delay
T delay
T delay
delay
P06.06
P06.08
P06.10
P06.12
Digital switch-on delay
The table below lists the options for the above four function parameters, and users are allowed
to select the same output terminal functions repetitively.
Set
value
Function
Description
0
Invalid
Output terminal has no function
1
In running
Output ON signal when there is frequency
output during running
2
In forward running
Output ON signal when there is frequency
output during forward running
3
In reverse running
Output ON signal when there is frequency
output during reverse running
4
In jogging
Output ON signal when there is frequency
output during jogging
5
VFD fault
Output ON signal when VFD fault occurred
6
Frequency level detection FDT1
Refer to P08.32 and P08.33
7
Frequency level detection FDT2
Refer to P08.34 and P08.35
8
Frequency reached
Refer to P08.36
9
Running in zero speed
Output ON signal when the VFD output
frequency and reference frequency are both
zero.
10
Reach upper limit frequency
Output ON signal when the running frequency
reaches upper limit frequency
11
Reach lower limit frequency
Output ON signal when the running frequency
reached lower limit frequency
12
Ready to run
Main circuit and control circuit powers are
established, the protection functions do not act;
when the VFD is ready to run, output ON signal.
13
In pre-exciting
Output ON signal during pre-exciting of the VFD
14
Overload pre-alarm
Output ON signal after the pre-alarm time
elapsed based on the pre-alarm threshold; see
P11.08–P11.10 for details.
15
Underload pre-alarm
Output ON signal after the pre-alarm time
elapsed based on the pre-alarm threshold; see
P11.11–P11.12 for details.
