INVT GD350-015G/018P-45-AS

Goodrive350 IP55 High-ingress Protection Series VFD Function parameter list
-219-
Function
code
Name
Description
Default
value
Modify
P22.01
Speed of spindle
orientation
During spindle orientation, the speed of the
position point of orientation will be searched,
and then it will switch over to position control
orientation.
Setting range: 0.00–100.00Hz
10.00Hz
○
P22.02
Deceleration
time of spindle
orientation
Deceleration time of spindle orientation.
Spindle orientation deceleration time means the
time needed for the VFD to decelerate from the
max. output frequency (P00.03) to 0Hz.
Setting range: 0.0–100.0s
3.0s
○
P22.03
Spindle zeroing
position 0
Users can select the zeroing positions of four
spindles by terminals (function code 46, 47).
Setting range: 0–65535
0
○
P22.04
Spindle zeroing
position 1
Setting range: 0–65535
0
○
P22.05
Spindle zeroing
position 2
Setting range: 0–65535
0
○
P22.06
Spindle zeroing
position 3
Setting range: 0–65535
0
○
P22.07
Spindle
scale-division
angle 1
Users can select seven spindle scale-division
values by terminals (function code 48, 49 and
50).
Setting range: 0.00–359.99
15.00
○
P22.08
Spindle
scale-division
angle 2
Setting range: 0.00–359.99
30.00
○
P22.09
Spindle
scale-division
angle 3
Setting range: 0.00–359.99
45.00
○
P22.10
Spindle
scale-division
angle 4
Setting range: 0.00–359.99
60.00
○
P22.11
Spindle
scale-division
angle 5
Setting range: 0.00–359.99
90.00
○
P22.12
Spindle
scale-division
angle 6
Setting range: 0.00–359.99
120.00
○
P22.13
Spindle
scale-division
angle 7
Setting range: 0.00–359.99
180.00
○
P22.14
Spindle drive
ratio
This function code sets the reduction ratio of the
spindle and the mounting shaft of the encoder.
Setting range: 0.000–30.000
1.000
○
P22.15
Zero-point
communication
P22.15 sets spindle zero-point offset, if the
selected spindle zero point is P22.03, the final
0
○
