Goodrive350 series high-performance multi-function inverter Appendix A
-268-
Appendix A Extension cards
A.1 Model definition
EC - PG 5 01 – 05
① ② ③ ④ ⑤
Field identifier
Field description
Naming example
①
Product category
EC: Extension card
②
Card category
PG: PG card
PC: PLC programmable card
IO: IO extension card
TX: Communication extension card
③
Technical version
Indicates the generation of a technical version by
using odd numbers, for example, 1, 3, and 5
indicate the 1
st
, 2
nd
, and 3
rd
generations of the
technical version.
④
Distinguishing code
01: Incremental PG card + frequency-divide output
02: Sine/Cosine PG card + pulse direction setting +
frequency-divide output
03: UVW PG interface + pulse direction setting +
frequency-divide output
04: Resolver PG interface + pulse direction setting +
frequency-divide output
05: Incremental PG card + pulse direction setting +
frequency-divide output
06: Absolute PG interface + pulse direction setting +
frequency-divide output
07: Reserved 2
⑤
Working power
00: Passive
05: 5V
12: 12–15 V
24: 24 V
