Goodrive350 series high-performance multi-function inverter Appendix A
-279-
EC-PG505-12 terminal function description
Label
Name
Function description
PWR
Encoder power
Voltage: 5 V/12 V ±5%
Max. output: 150 mA
Select the voltage class through the DIP switch
SW1 based on the voltage class of the used
encoder.
PGND
A1+
Encoder interface
1. Supporting push-pull interfaces of 5 V/12 V
2. Supporting open collector interfaces of 5 V/12 V
3. Supporting differential interfaces of 5 V
4. Response frequency: 200 kHz
A1-
B1+
B1-
Z1+
Z1-
A2+
Pulse setting
1. Supporting the same signal types as the
encoder signal types
2. Response frequency: 200 kHz
A2-
B2+
B2-
Z2+
Z2-
AO+
Frequency-divided
output
1. Differential output of 5 V
2. Supporting frequency division of 1–255, which
can be set through P20.16 or P24.16
AO-
BO+
BO-
ZO+
ZO-
