INVT GD350-2R2G-4 User Manual

Goodrive350 series high-performance multi-function inverter Appendix C
-301-
C.3 Inverter structure
Fig C.3 Inverter structure diagram
C.4 Dimensions of Inverters of AC 3PH 380V (-15%)–440V (+10%)
C.4.1 Wall-mounting dimensions
W1
H1
D1 W2
H2
Fig C.4 Wall-mounting diagram of inverters of 380 V, 1.5 to 37 kW
