Goodrive350 series high-performance multi-function inverter Appendix C
-303-
W1
W2
D1
H1 H2
6- ø13.0
W2
Fig C.8 Wall-mounting diagram of inverters of 380 V, 220 to 315 kW
Table C.1 Wall-mounting dimensions of 380 V inverters (unit: mm)
Inverter
specification
W1
W2
W3
H1
H2
D1
Installation
hole
diameter
Fixing
screw
1.5kW–2.2kW
126
115
-
186
175
185
5
M4
4kW–5.5kW
126
115
-
186
175
201
5
M4
7.5kW
146
131
-
256
243.5
192
6
M5
11kW–15kW
170
151
-
320
303.5
220
6
M5
18.5kW–22kW
200
185
-
340.6
328.6
208
6
M5
30kW–37kW
250
230
-
400
380
223
6
M5
45kW–75kW
282
160
226
560
542
258
9
M8
90kW–110kW
338
200
-
554
535
330
10
M8
132kW–
200kW
500
180
-
870
850
360
11
M10
220kW–
315kW
680
230
-
960
926
380
13
M12
C.4.2 Flange installation dimensions
H1 H2
W1
W2
D1
D2
W3
W2
W4
H4
H2H3
