Goodrive350 series high-performance multi-function inverter Appendix D
-323-
Note:
1. The rated input voltage drop of input reactors is 2%±15%.
2. The current adjustment coefficient on the input side of the inverter is higher than 90% after a DC
reactor is configured.
3. The rated output voltage drop of output reactors is 1%±15%.
4. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
D.7 Filters
J10 is not connected in factory for inverters of 380V (≤ 110kW). Connect the J10 packaged with the
manual if the requirements of level C3 need to be met;
J10 is connected in factory for inverters of 380V (≥ 132kW), all of which meet the requirements of
level C3.
Note:
Disconnect J10 in the following situations:
1. The EMC filter is applicable to the neutral-grounded grid system. If it is used for the IT grid
system (that is, non-neutral grounded grid system), disconnect J10.
