Goodrive350 series high-performance multi-function inverter Chapter 5
-92-
Set
value
Function
Description
SVPWM control.
60
Switch to FVC control
When this terminal is valid in stop state, switch to
closed-loop vector control.
61
PID polarity switch-over
Switching the output polarity of PID, this terminal should
be used in conjunction with P09.03
66
Zero out the counter
Zero out the position counting value
71–79
Reserved variables
/
Related parameter list:
Function
code
Name
Detailed parameter description
Default
value
P05.00
HDI input type
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0x00
P05.01
Function of S1 terminal
0: No function
1: Forward running
2: Reverse running
3: Tri-line running control
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10: Frequency increase (UP)
11: Frequency decrease (DOWN)
12: Clear frequency
increase/decrease setting
13: Switch-over between setup A and
setup B
14: Switch-over between
combination setting and A setting
15: Switch-over between
combination setting and setup B
16: Multi-step speed terminal 1
1
P05.02
Function of S2 terminal
4
P05.03
Function of S3 terminal
7
P05.04
Function of S4 terminal
0
P05.05
Function of HDIA terminal
0
P05.06
Function of HDIB terminal
0
P05.07
Reserved variables
0
