Goodrive350 series high-performance multi-function inverter Chapter 5
-94-
Function
code
Name
Detailed parameter description
Default
value
input
59: Switch to V/F control
60: Switch to FVC control
61: PID polarity switch-over
66: Zero out encoder counting
67: Pulse increase
68: Enable pulse superimposition
69: Pulse decrease
70: Electronic gear selection
71–79: Reserved
P05.08
Polarity of input terminal
0x00–0x3F
0x00
P05.09
Digital filter time
0.000–1.000s
0.010s
P05.10
Virtual terminal setting
0x00–0x3F (0: disable, 1: enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT8: HDIB virtual terminal
0x00
P05.11
Terminal control running mode
0: Dual-line control 1
1: Dual-line control2
2: Tri-line control 1
3: Tri-line control 2
0
P05.12
S1 terminal switch-on delay
0.000–50.000s
0.000s
P05.13
S1 terminal switch-off delay
0.000–50.000s
0.000s
P05.14
S2 terminal switch-on delay
0.000–50.000s
0.000s
P05.15
S2 terminal switch-off delay
0.000–50.000s
0.000s
P05.16
S3 terminal switch-on delay
0.000–50.000s
0.000s
P05.17
S3 terminal switch-off delay
0.000–50.000s
0.000s
P05.18
S4 terminal switch-on delay
0.000–50.000s
0.000s
P05.19
S4 terminal switch-off delay
0.000–50.000s
0.000s
P05.20
HDIA terminal switch-on delay
0.000–50.000s
0.000s
P05.21
HDIA terminal switch-off delay
0.000–50.000s
0.000s
P05.22
HDIB terminal switch-on delay
0.000–50.000s
0.000s
P05.23
HDIB terminal switch-off delay
0.000–50.000s
0.000s
P07.39
Input terminal state of present
/
0
