iPECS eMG80 - Page 22

iPECS eMG80
Hardware Description and Installation Manual Issue 1.0
15
Table 2.5.2-5 KSUID Device Type Maximums
Resource
Type
Device Maximum Capacity Interface Boards
External
Network
KSUID: 0 CO & 8 DKT + 4 SLT & 2 VoIP
CO Line 8 2 CH408 or 1 CH408 + 1 CS416
BRI Line 6 (2B+D) 1 BRIU + 2 BH408
PRI/E1 Line 30 channels 1 PRIU
SIP Trunk 16 channels
6-licensed + VVMU
Shared w/Local/Remote IP &SIP phones
KSUID
CO Line 12 2 CH408 or 1 CH408 + 1 CS416
KSUID + EKSU
CO Line 20
BRI Line 6 (2B+D) & 12 CO Line
PRI/E1 Line 30 channels
SIP Trunk 16 channels
Stations
KSUID
DKT 24 & 4 SLTs 2 CH408 or BH208 or combination
SLT 28 & 8-DKT 1 (CH408 or BH208) + 1 CS416
LIP/SIP 32
6-licensed + VVMU
Shared w/SIP Trunks
16 simultaneous calls
DECT 48
WTIB4
24 simultaneous calls
EKSU
DKT 24 2 CH408
SLT 32 1 CH408 +1CS416
KSUID + EKSU
DKT 48 & 4 SLT
SLT 60 & 8-DKT
LIP/SIP 32 SIP Phones require per seat license
DECT 48
