Hardware Description and Installation Manual Issue 1.0
33
The following chart lists the various connectors for option boards, RJ modular jacks for
connecting CO Lines, Stations and miscellaneous functions, and switches on the Main
Board.
Connectors, Jacks and Switches
Table 4.5.3-1 KSU with MBUI Connector, Modular Jack and Switch Function
Connector Functions Remark
CN1 CO and Extension board installation 70 pins
CN2 PRIU or BRIU2 Installation 40 pins
CN4 MODU Installation 20 pins
CN5 & CN6 Connection KSU to EKSU with Expansion cable 19 pins x 2
CN7 PSU Connector 7 pins
CN10 FPGA JTAG for development 10 pins
CN11 RS-232C Port Connection 9 pins
CN12 CPU JTAG for development 20 pins
CN15 MEMU Installation 20 pins
MJ2 1 DKT and 7 Hybrid DKT or SLT ports 8 ports
MJ3 LAN & USB Port 1 LAN/1 USB
MJ4 Relay/Alarm/Page/External MOH Connection 1 Port
SW1 2 pole Database protect switch
SW2 Push-button System reset switch
Table 4.5.3-2 MBUI SW1 – 2-pole Dip switch
Switch setting
Pole Function
Switch State
Remarks
ON OFF
1
Database
protection
Protect database, no
admin allowed
Unprotect Default = OFF
2
Initialization for
Database
Initialize Database on
reset
Use stored Database Default = ON
Table 4.5.3-3 MBUI LED Indication
LED Indications
LED Color
Description
LD1
Blue
Flash 300ms ON and OFF, normal operation
LD2 Blue Station port in use status
ON - A station is in use
OFF - All station are idle
LD3 Green External Clock Synchronization
ON: PLL circuit sync to ISDN interface clock
OFF: PLL circuit sync to internal clock
