4. If not using a POE switch port, connect the DC connector of an AC Adaptor-K to the
DC input on the bottom of the IP Phone and plug the AC plug of the AC adaptor in to
a 100-240 VAC outlet.
Once the LIP phone powers up, it will attempt to register with the eMG80. From default, the
LIP phone should complete the registration successfully. If not, the phone will display the
“No Response” message shown below.
NO RESPONSE FROM MFIM [L]
SET[*] – RETRY[#]
This indicates the LIP phone needs to be configured for the local network environment. To
configure the phone, perform the following steps.
1. Press ‘*’ to set the network configuration
2. Enter the password, 147*.
3. Use the Volume Up/Down buttons to scroll through the menu shown below.
4. Enter appropriate values for the local network.
5. When complete, press the Speaker button.
6. Press ‘*’ to exit and restart the LIP Phone.
Menu Display
Description
MODE[R/L]
[LOCAL] – CHANGE[#]
Registration mode, use ‘#’ to set Remote mode
PHONE IP ADDRESS (DOT:*) Use the dial pad to enter the fixed IP address,
use DHCP for dynamic addressing
PHONE NET MASK(DOT:*) Use the dial pad to enter the Subnet mask if
using fixed IP addressing
ROUTER IP ADDRESS(DOT:*) Use the dial pad to enter the default Gateway if
using fixed IP addressing
MFIM IP ADDRESS(DOT:*) Use the dial pad to enter the IP address of the
MFIM IP address.
SAME LAN WITH MFIM
[YES] – CHANGE[#]
Indicates if the IP Phone and the eMG80 are on
the same LAN segment. Use # to change,
Yes/No.
INPUT DEVICE NUMBER:
DHCP ?
[DISABLED] – CHANGE[#]
The IP Phone supports fixed or dynamic
addressing, use # to change the value.
VLAN CONFIGURATION
NOT SET
Not used
WEB PASSWORD Not used
PHY MODE : AUTO NEGO
CHANGE[*] SAVE[#]
Speed and Duplex negotiation, use * to change
the selection
