Iridium EDGE - Environmental Specifications

27
2.5 Accessories
The Iridium Edge ships with an Accessory Bag with parts for use when the Iridium Edge is installed with a
bottom mount screw. More details on this installation is described in Section 5.6 Mounting the Iridium
Edge.
The Accessory Bag contains the following items as illustrated in the figure below:
Figure 2-5 Accessory Bag Contents
1. 2. 3. 4.
1- Slotted Nut 2 - Rubber Grommet 3- Slotted Screw 4- Spiral Sheath
2.6 Temperature
The Iridium Edge’s temperature specifications are summarized in Table 2-1 below.
Table 2-1 Temperature Specifications
Parameter
Value
Operating Temperature Range
-40ºC to + 85ºC
Storage Temperature Range
-40ºC to + 85ºC
2.7 Environmental
The environmental specifications of the Iridium Edge are summarized in the table below. All Iridium Edge
testing has been performed with a mated IP67 connector connected to its pigtail.
