Iridium EDGE - Enclosure Dimensions; Mount Holes

31
Figure 2-8 Enclosure Top View
Figure 2-9 Enclosure Side View
2.9.1 Enclosure Dimensions
Table 2-5 Enclosure Specifications
Parameter
Value
Length
123.2 mm
Width
78.4 mm
Height
30.3 mm
2.9.2 Mount Holes
As per figure below, the Iridium Edge has two screw holes on each of its ends to mount the terminal. It is
important to use screws with low profile heads so that satellite antenna performance is not affected.
