2.11 Mass
The table below provides the mass specification for the Iridium Edge
Table 2-9 Mass Specification
Parameter
Value
Mass
205 (+/- 10 g)
3 Electrical and RF Specifications
The following subsections contain interface information for the electrical interfaces of the Iridium Edge.
3.1 Power Interface
3.1.1 Input Specification
The table below provides the voltage input specification for the Iridium Edge. The power and ground
inputs are reverse polarity protected.
Table 3-1 Input Power Specification
Parameter
Value
Input Range
9 – 32V DC
Reverse Polarity Protection
32 VDC
3.1.2 Current Limiting
The Iridium Edge restricts the input current draw to minimize the voltage difference between the Iridium
Edge’s internal ground reference and the external power supply. The maximum current specification is
provided in the table below.
