6 Appendix A: Blunt Cut Cable
A Blunt Cut cable accessory is available from Iridium for its distribution partners. It can be ordered using
the part number in the table below
It is recommended that partners cut the cable to the required length to ensure a simple clean installation.
The cable drawings including color codes for the optional Blunt cables are shown below. As per notes in
the Pin Out Configuration drawing below, the shielded drain wire is connected to the ground pin. The
braid wire at the blunt cut side, should be left unterminated to ensure that there is a single point ground
for the cable shielding.
Figure 7-1 Blunt Cut Cable
