IRIS IRMA MATRIX Door Clear User Manual

7
/30
IRMA MATRIX Door Clear option | Mounting and operating instructions
released
Rev. 1.3
2018-08
Fig. 2: Signal chain for Door Clear in ETH wiring
2.3 Connection via CAN direct integration
For a 2-door bus (middle door: approx. 1.25m x 2.10m) with two IRMA MATRIX sensors, for
example, perform the installation via CAN direct integration as follows:
follow the instructions in the document
KDIA_IRMA-MATRIX_R2_Installationsanleitung-CAN_1.5, available at
https://www.irisgmbh.de/technische-dokumente/irma-matrix/. Fig. 3
shows the simplified
Door Clear signal chain for sensor installation via CAN direct integration.
Fig. 3: Signal chain for Door Clear with CAN direct integration
IRMA MATRIX
Surface
mounted
version
IRMA MATRIX
(surface-
mounted
version)
