IRIS IRMA MATRIX Door Clear User Manual

9
/30
IRMA MATRIX Door Clear option | Mounting and operating instructions
released
Rev. 1.3
2018-08
8 SWb Out ‘b’ contact
voltages.
9 SWa Out ‘a’ contact
Door Clear door 4
10 SWb Out ‘b’ contact
Note Fig. 5 for the “V” outputs of the door control analyzer:
Fig. 5: Pin assignment for Door Clear on the door control analyzer
2.5 Connecting the sensor to the PC
To configure the sensor and Door Clear, you need a laptop with Windows XP, Vista, 7 or 8.
The service laptop is connected either via Ethernet or CAN.
