I A P 2 0 2 3 . 0 0 1 - A F M / I R I S T E X A N I I P A G E | 117
FOR SIMULATION USE ONLY – NOT A TRAINING AID
SYS - DISPLAY
On the SYS top-level page, depressing the arrow key next to W3 DISPLAY allows
pilots to access lower level system pages.
Key Window Action
SYS - DISPLAY
HUD W1 - Provides access to the HUD page.
TCAS W2 – Provides access to the TCAS page.
G W3 - Provides access to the G limits page.
MFD W4 - Provides access to the MFD page.
SYS - DISPLAY - TCAS
On the lower-level system page, the TCAS page is a navigation window that allows
pilots to view and change the TCAS system status, system mode, and flight level
setting.
SYS-DISPLAY-TCAS is also directly accessed by pressing LSK R2 on the NAV
display.
Key Window Action
SYS – DISPLAY
- TCAS
TCAS ON or
SBY
W1 - Is a selection window labelled TCAS with
options ON and SBY.
The selection in this window controls the TCAS
system mode. Pressing W1 toggles the TCAS status
from ON and SBY and displays on both crew
stations.
ABOVE,
NORMAL, or
BELOW
W2 – Is a selection window with options ABOVE,
NORMAL, and BELOW.
The selection in this window controls the TCAS
system mode. Pressing W2 toggles through the
TCAS look angle options ABOVE, NORMAL, and
BELOW, and displays on both crew stations.
FL REL or
ABS
W3 - Labelled FL and has options REL and ABS.
Pressing W3 toggles through the TCAS flight level
setting options FL REL and FL ABS, and displays
on both crew stations. The selection in this window
controls the TCAS system flight level setting.
