I A P 2 0 2 3 . 0 0 1 - A F M / I R I S T E X A N I I P A G E | 119
FOR SIMULATION USE ONLY – NOT A TRAINING AID
SYS - DISPLAY - MFD
On the lower-level system page, the MFD page allows pilots to view and change the
MFD declutter level.
Key Window Action
SYS – DISPLAY
- MFD
DCLTR 0, 1
or 2
W1 - Is a selection window with the label DCLTR
and options 0, 1, or 2.
Pressing W1 toggles between the available MFD
declutter selections. The selection in this window
controls the MFD declutter level.
W2 - Has no display or control functionality.
W3 - Has no display or control functionality.
W4 - Has no display or control functionality.
SYS - DISPLAY – BGO/IP
On the SYS top-level page, depressing the arrow key next to W4 BINGO allows
pilots to view and change the bingo fuel level setting. BINGO is also directly
accessed by pressing LSK L3 on the EICAS display.
Key Window Action
SYS –
BINGO/IP
BGONNNN
W1 - Is a data entry window with the label BGO
and data consisting of a number with up to 4 digits
indicating the bingo fuel level setting (in lbs.),
which has an allowable range of 0 to
1200.
The pilot can insert a new bingo fuel setting using
the alphanumeric keyboard followed by a press of
the ENT button.
IP
W2 - Displays IP right justified and is a navigation
window that allows the pilot to access waypoint
offset (Initial Point) functions when W2 is
depressed.
W3 - Has no display or control functionality.
W4 - Has no display or control functionality.
