I A P 2 0 2 3 . 0 0 1 - A F M / I R I S T E X A N I I P A G E | 121
FOR SIMULATION USE ONLY ā NOT A TRAINING AID
range (for a B offset).
For an along track distance, the label is displayed
as Y and the data is a number with up to four digits
indicating the along track distance, which has an
allowable range of 0 to 999.9 nm.
For an offset range, the label is displayed as R and
the data is a number with up to three digits
indicating the offset range, which has an allowable
range of 0 to 99.9 nm.
When the along track distance or the offset range
is entered using the alphanumeric keyboard, the
decimal point is automatically displayed in the
second character position from the right.
Pressing ENT activates this change.
CONFIRM
W4 - Displays CONFIRM when the desired offset
point can be created.
Pressing W4 confirms and executes the new flight
plan and W4 becomes blank.
Clock (CLK)
The CLK hard key displays the current clock time and provides a count-up timer
function. When the user re-enters the clock page, after allowing it to run in the
background, the setting of Window 1 and 2 displays the standard default settings
and the setting of Window 3 displays either stopped time or running time depending
on what was displayed when the user last exited the page.
