15
Connecting the Power Source
Connecting the Power Supply - Indoor Models
Indoor models ship prewired with a power cord ready to be plugged into
a standard wall power socket.
Note: To immediately test-run the Rain Dial-R irrigation control system,
refer to the “Controller Station Test Feature” on page 8.
EARTH
GROUND
7
8 9 10 11 12
24 VAC
VC
MV/
Pump
Sensor
+
-
1 2
3 4 5 6
Figure 8
