TXG23
SPECIFICATIONS
TXG23
ENGINE:
Make Iseki Diesel
Model E3112-B12
Type Indirect injection, overhead valve
Aspiration Natural
Displacement 1123 cc
Number of Cylinders 3
Bore 78.2 mm
Stroke 78.0 mm
Engine Horsepower (Gross) 22.5 HP (16.8 kW) @ 2600 rpm
(Net) 22.0 PS (16.1 kW) @ 2600 rpm
PTO Horsepower (Estimate) 17.5 @ 555 PTO rpm
Firing Order 1-3-2
Compression Ratio 22.5 to 1
Low Idle Speed 1250 to 1300 rpm
High Idle Speed 2760 to 2860 rpm
Valve Clearance (Cold);Intake 0.25 mm
Exhaust 0.25 mm
Air Cleaner Single stage, dry element
Engine Cooling Liquid, forced circulation
Cold Starting Aid Glow plugs (3)
TRANSMISSION:
Type; Primary Infinite
Range 2speed constant mesh
Gear Speeds 2gears forward, 2 reverse
Clutch None
Brakes Mechanically actuated sealed wet disk
POWER TAKE-OFF (PTO):
Type Independent, engine drive
Control Hydraulic control
Clutch Mechanically engaged, multi-plate wet disk
Rear PTO; Shaft 35 mm diameter, six spline
Output Clockwise rotation
Engine Speed @ 540 PTO rpm 2532 rpm
Mid PTO; Shaft 25.4 mm diameter, fifteen spline
Output Clockwise rotation
Engine Speed @ 2000 PTO rpm 2476 rpm
